Front Cross Tube Arm Replacement
TM 9-2320-363-34-1 · Chapter 5 — Front Axle Maintenance
This task covers: a. Removal b. Cleaning c. Inspection d. Installation
Tools and Special Equipment: Equipment Condition:
Shop Equipment, SC 4910-95-CL-A31 Reference Condition Description
Tooi Kit, SC 5180-90-CL-N05
Page 5-52 Tie Rod Removed
Materials/Parts:
Pin, Cotter
NOTE
Procedure is the same for both cross tube arms.
REMOVE COTTER PIN (1), CASTELLATED NUT (2), CROSS TUBE ARM (3), AND WOODRUFF
KEY (4). DISCARD COTTER PIN.
TM page 5-59
Use general cleaning methods to clean all parts (page 2-30).
Inspect all parts for wear or damage.
NOTE Procedure is the same for both cross tube arms.
1. INSTALL WOODRUFF KEY (4), CROSS TUBE ARM (3), AND CASTELLATED NUT (2). TIGHTEN CASTELLATED NUT TO 550-740 LB-FT (746-1003 N.m).
CAUTION Castellated nut may be tightened to 1,025 Ib-ft (1390 N.m) for purpose of installing cotter pin. Overtightening may damage steering arm.
2. INSTALL NEW COTTER PIN (1).
NOTE Follow-on Maintenance:
Install tie rod (page 5-52).
TM page 5-60
