2-28. Oil Filter Adapter and Oil Pressure Sending Unit Repair

TM 9-2815-237-34 · Chapter 2 — Engine Maintenance

This task covers:

a. Cleaning b. Inspection

INITIAL SETUP

    Tools                                               Equipment Condition
      General mechanic’s tool kit                         Engine disassembled into subassemblies
       automotive (Appendix E, Item 1)                    (para. 2-15).
    Manual References
      TM 9-2815-237-34P

    a. Cleaning

Clean all components in accordance with para. 2-9.
    b. Inspection

                                                  NOTE
                          For general inspection instructions, refer to para. 2-10.
1. Inspect adapter bolt (2) for damaged threads. Replace if threads are damaged.
2. Inspect adapter reducer (3) for damaged threads. Replace if threads are damaged.
3. Inspect adapter (1) for damage. Replace adapter (1) if damaged and remove adapter reducer (3)
     for reuse.
4. Inspect fitting (5) for damage. Replace if damaged.
5. Inspect oil pressure sending unit (4) for damage. Replace if damaged.
