GENERAL INFORMATION

TM 9-2815-225-34&P · Work Package 0001 00

THIS WORK PACKAGE (WP) COVERS:

Scope; Maintenance Forms, Reporting Equipment Improvement Recommendations (EIRs); Corrosion Prevention and Control (CPC); Destruction of Army Materiel to Prevent Enemy Use; Preparation for Storage or Shipment; Warranty Information; List of Abbreviations; Quality of Material; Safety, Care and Handling.

SCOPE

This manual contains repair procedures and supplemental data for the Cummins NTC-400 six-cylinder, in-line, turbocharged diesel engine. The repair procedures in this manual are for use at direct support and general support maintenance levels. All information contained in this manual applies to both Big Cam I and Big Cam III engines except where differences are specifically noted.

MAINTENANCE FORMS

Department of the Army forms and procedures used for equipment maintenance will be those prescribed by DA PAM 738-750, Functional Users Manual for The Army Maintenance Management System (TAMMS).

REPORTING EQUIPMENT IMPROVEMENT RECOMMENDATIONS (EIR’S)

If your Cummins NTC-400 six cylinder diesel engine needs improvement, let us know. Send us an EIR. You, the user, are the only one who can tell us what you don’t like about your equipment. Let us know what you don’t like about the design or performance. The preferred method for submitting Quality Deficiency Reports (QDRs) is through the Army Electronic Product Support (AEPS) website under the Electronic Deficiency Reporting System (EDRS). The web address is: https://aeps.ria.army.mil. This is a secured site requiring a password that can be applied for on the front page of the website. If the above method is not available to you, put it on an SF 368, Product Quality Deficiency Report (PQDR), and mail it to us at: Department of the Army, U.S. Army Tank-automotive and Armaments Command, ATTN: AMSTA-LC-CHMM, 6501 E. 11 Mile Road, Mail Stop 420, Warren, MI 48397-5000. We’ll send you a reply.

CORROSION PREVENTION AND CONTROL (CPC)

Corrosion Prevention and Control (CPC) of Army materiel is a continuing concern. It is important that any corrosion problem with this item be reported so that the problem can be corrected and improvements made to prevent the problem in the future. While corrosion is typically associated with rusting of metals, it can also include deterioration of other materials, such as rubber and plastic. Unusual cracking, softening, swelling, or breaking of these materials may be a corrosion problem. If a corrosion problem is identified, it can be reported using an SF 368, Quality Deficiency Report. Use of key words, such as corrosion, rust, deterioration, or cracking, will ensure that the information is identified as a CPC problem. The form should be submitted to the address specified in DA PAM 738-750, Functional Users Manual for The Army Maintenance Management System (TAMMS).

DESTRUCTION OF ARMY MATERIEL TO PREVENT ENEMY USE

Procedures for destruction of Army equipment to prevent enemy use can be found in TM 750-244-6.

PREPARATION FOR STORAGE OR SHIPMENT

Information concerning storage or shipment of equipment can be found in TM 740-90-1. Additional information concerning storage of Cummins NTC-400 engine can be found in Chapter 3, Maintenance Instructions.

WARRANTY INFORMATION

The Cummins diesel engine (model NTC-400) is warranted in accordance with TB 9-2300-295-15/21. The warranty starts on the date found in block 23, DA Form 2408-9. Report all defects in material or workmanship to your supervisor, who will take appropriate action.

LIST OF ABBREVIATIONS

AFC . . . . . . . . . . . . . . . . . . . . . . . . Air Fuel Control kPa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .kilopascal ASA . . . . . . . . . . . . . . . . . . .Air Signal Attenuator L . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .liter BHP . . . . . . . . . . . . . . . . . . . . . .Brake Horsepower lb-ft . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pound foot C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Celsius lb/hr . . . . . . . . . . . . . . . . . . . . . . . .pounds per hour CFM . . . . . . . . . . . . . . . . . . . .cubic feet per minute lb-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . .pound inch CPC . . . . . . . . . .Corrosion Prevention and Control N•m . . . . . . . . . . . . . . . . . . . . . . . . . .Newton meter cu in. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .cubic inch pph . . . . . . . . . . . . . . . . . . . . . . . . .pounds per hour EIR . . . . . . . . . . . . . . . . .Equipment Improvement PQDR . . . . . . . .Product Quality Deficiency Report Recommendations PT . . . . . . . . . . . . . . . . . . . . . . . . . .Pressure Timed EPA . . . . . . . . . .Environmental Protection Agency psi . . . . . . . . . . . . . . . . . . . .pounds per square inch f . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .foot rpm . . . . . . . . . . . . . . . . . . .revolutions per minute F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Fahrenheit STE/ICE . . . . . . . . .Simplified Test Equipment for ft alt . . . . . . . . . . . . . . . . . . . . . . . . . . .feet altitude Internal Combustion Engines QDR . . . . . . . . . . . . . . . .Quality Deficiency Report TAMMS . . . . . . . . . . . . . . .The Army Maintenance Hg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Mercury Management System hp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . horsepower TM . . . . . . . . . . . . . . . . . . . . . . . .Technical Manual in. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .inch WP . . . . . . . . . . . . . . . . . . . . . . . . . . .Work Package kg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .kilogram

QUALITY OF MATERIAL

Material used for replacement, repair, or modification must meet the requirements of this manual. If quality of material requirements are not stated in this manual, the material must meet the requirements of the drawings, standards, specifications, or approved engineering change proposals applicable to this Cummins engine.

SAFETY, CARE, AND HANDLING

Adequate safety precautions will be provided for the performance of maintenance operations. These precautions will include safety in work environment, selection and usage of equipment, and procedures provided for performing all operations. Inspection, which follows completion of maintenance procedures, will ensure equipment compliance with applicable safety standards. Supplies and materials such as cleaning fluids, sealers, adhesives, oils, and other products used in this manual may be dangerous or harmful if safety precautions are not observed. Read manufacturers’ warnings and cautions on product labels before using and observe all recommended safety precautions. Ensure proper procedures are followed during lifting of heavy items. Follow all warnings and cautions identified in this manual.

END OF WORK PACKAGE
